规格specification | VMC-1160 |
X轴行程X - Axis Travel | 1300mm |
Y轴行程Y - Axis Travel | 700mm |
Z轴行程Z - Axis Travel | 620mm |
主轴端面至工作台距离Spindle Nose To Table | 140-760mm |
主轴中心至滑道面距离Spindle Center To Z-Rail | 705mm |
工作台尺寸Table Size | 1410*660mm |
T型槽（槽数*宽*间距）T - Slot | 5*18mm*125mm |
最大荷重Maximum Table Load | 1200kg |
刀具锥度Spindle Taper | BT50 |
转速Spindle RPM | 6000/8000rpm(option)/6000rpm |
传动方式Type Of Driving | 皮带式Belt Type/齿轮二段式Gear Head Type |
X、Y轴快送X. Y Axis Rapid Feed Rate | 18m/min |
Z轴快送Z Axis Rapid Feed Rate | 15m/min |
X、Y、Z最大切削进给速度 X. Y. Z Max. Cutting Feed Rate | 6m/min |
斗笠式Geneva Type (Tool to Tool) | 16T (8sec) |
刀臂式Arm Type (Tool to Tool) | 24T (4.5sec) |
主轴马达Spindle Motor | SJ-V15(15kw)/ Aif15 (15kw) |
X、Y轴向马达X. Y Servo Motor | HF-354(3.5kw)/ Aif 22 (4.0kw) |
Z轴向马达Z Servo Motor | HF-354 (3.5kw)/ Aif 22(4.0kw) |
切削水马达Coolant Pump Motor | 670W |
刀库马达Motor of tool Change System | 斗笠式Geneva Type 60W /刀臂式Arm Type 200W |
排屑马达Chip Conveyor Motor | 1/4HP |
定位精度（JIS标准）Positioning Accuracy (JIS) | + /-0.005mm/300mm |
重复精度（JIS标准） Repeat Positioning Accuracy (JIS) | + /-0.003mm |
机械占地面积（长*宽*高） Floor Space Measurement | 3530*2670*2550 |
机械包装尺寸（长*宽*高） Packaging Measurement | 3630*2770*2650 |
机械重量（约）Approximate Weight | 10200kg |
