技术参数Technical Specifcations
项目Project | 单位 | VMC-1300 | VMC-1500 | VMC-1600 | VMC-1800 | |||
工作台面积 Areaworking tale | mm | 1400*710 | 1700*800 | 1800*900 | 2000*900 | |||
XYZ轴行程 xyz axle travel | mm | 1300/700/650 | 1500/800/700 | 1600/900/680 | 1800/900/680 | |||
T型槽(数目-尺寸×间距) T-slot(number-dimension×interval) | 18mm*4个 | 18mm*3个 | 18mm*5个 | 18mm*5个 | ||||
主轴鼻端至工作台距离 Distance between spindle nose and operating platform | mm | 150-800 | 170-870 | 160-840 | 160-840 | |||
主轴中心至立柱距离 Distance between spindle center to stand column | mm | 785 | 800 | 950 | 950 | |||
主轴转速 Rotaion speed of spindle | rpm | 8000 | 8000 | 8000 | 8000 | |||
主轴锥孔 Spindle taper | BT 50 | BT 50 | BT 50 | BT 50 | ||||
主轴电功率 Spindle motor power | HP | 15KW | 18.5KW | 18.5KW | 18.5KW | |||
三轴电功率 Triaxial motor power | KW | 3.5 | 4.5 | 4.5 | 4.5 | |||
XYZ轴快速进给 xyz axis rapid feed | mm/min | 14000*14000*12000 | 14000*14000*12000 | 14000*14000*12000 | 14000*14000*12000 | |||
XYZ轴切削进给 xyz axis cutting feed | mm/min | 1-6000 | 1-6000 | 1-6000 | 1-6000 | |||
定位及重新定位精度 Positioning and reposition accuracy | mm | ±0.005/300mm/±0.003/300mm | ||||||
工作台负荷 | kg | 1000 | 1000 | 1000 | 1000 | |||
电力需求 Power demand | kva | 30 | 45 | 45 | 45 | |||
空压规格 Air pressure specification | kg/cm | 6-7 | 6-7 | 6-7 | 6-7 | |||
机械重量 Machine weight | kg | 10500 | 13500 | 15000 | 15500 | |||
外形尺寸 Dimensions(L*W*H) | mm | 3700*3000*3100 | 4300*3200*33000 | 4400*3500*3400 | 4500*3500*3400 | |||
